TouchScreen Monitors |
|
|
| Product name : TouchScreen Monitors |
| Item : FOX-700TK |
| Details : |
|
Name:
|
Touch Screen Monitors(FOX-700TK) |
|
Spec:
|
FOX-700TK |
|
Memo:
|
17",high resolution lcd touch screen monitor |
|
Class:
|
Touchscreen Displays |
|
Specification
|
FOX-700TK
|
|
LCD Panel style
|
17'' TFT LCD Panel
|
|
Screen Ratio
|
4:3
|
|
Resolution
|
1366 * 768
|
|
Active Display Area
|
337 x 270
|
|
Contrast Ratio
|
450:1
|
|
Brightness
|
300 cd//m²
|
|
Pixel Pitch
|
0.264 mm
|
|
Color
|
16.7M
|
|
Viewing Angle
|
178°/178°
|
|
Response Time
|
8ms
|
|
Working Environment
|
Temperature: -10℃ ~ 60℃
|
|
Power Supply
|
100-240V AC, 50/60Hz
|
|
Consumption
|
≤30W
|
|
Touch Type
|
Resistive Touch (4-wire /5 wire), SAW, Infrared Touch optional
|
|
Touch-screen reponse speed
|
≤10ms
|
|
Touch-screen surface hardness
|
3H
|
|
Touchscreen transmittance
|
>85%
|
|
Touch-screen life
|
>35 million times
|
|
Touch Interface
|
USB or RS232 optional
|
|
Language
|
Chineseã€English(According to the request of customer customization)
|
|
 |
