Network Server |
|
|
| Product name : Network Server |
| Item : FNS-B756L-L |
| Details : |
1U 6 LAN ATX G41 /B75
|
Name:
|
Network Server(FNS-B756L-L) |
|
Spec:
|
FNS-B756L-L |
|
Memo:
|
Support LGA1155 1U Rack Server With 6*Intel 82583V |
|
Class:
|
Mini-ITX Motherboards |
Online Shop: http://www.aliexpress.com/store/312429
Payment Terms: T/T,Western Union,PAYPAL,ESCROW
Support LGA1155 1U Rack Server With 6*Intel 82583V
| Port: |
shenzhen |
| Minimum Order Quantity: |
5 Unit/Units |
| Supply Ability: |
5000 Unit/Units per Month |
| Payment Terms: |
L/C,T/T,Western Union,MoneyGram,paypal,escrow |
Packaging & Delivery
| Packaging Details: |
OEM |
| Delivery Detail: |
within 2~3 working days |
Specifications
Support Intel LGA1155 Socket Core i7/i5/i3/Pentium processor;
6*Intel 82583V Nics;
Support 4*SATA,1*mSATA,1*CF Card slot
Feature
- Intel LGA1155 Socket Core i7/i5/i3/Pentium processor
- Intel® B75 chipset
- Support Dual Channel SO DDRⅢ 1333/1066 memory,the biggest support 16G
- Provide 6 Intel 82583V gigabit nics,LAN1~4 support bypass function
- 1* Mini-PCIE,support WIFI/3G
- Support 4*SATA,1*mSATA,1*CF Card slot
Specification
|
CPU
|
Support LGA1155 Intel Core i7/i5/i3 Sandy Bridge processor
|
|
Chipset
|
Intel® B75
|
|
Memory
|
Support Dual Channel SO DDRⅢ 1333/1066,max up to 16GB
|
|
Display
|
1* DB15 VGA
|
|
Network
|
6*Intel 82583V
|
|
|
LAN1-LAN4 support BYPASS
|
|
|
1*Mini-PCIE,support WIFI,3G module
|
|
Storage
|
1*3.5/2.5'' SATA position and 1*MSATA,CF card slot
|
|
Expansion slot
|
1*PCIE 8x Gold finger
|
|
Interface
|
2* USB 2.0
|
|
|
6* LAN
|
|
|
1* COM(RJ45)
|
|
|
1* VGA
|
|
|
1* POWER
|
|
|
1* POWER_LED,HDD_LED
|
|
Cooling
|
1x CPU fan,2x system fan
|
|
Working Temp
|
-10°C~60°C
|
|
Storage Temp
|
-20°C~70°C
|
|
Working Hum
|
0-95%(relative humidity,no condensation)
|
|
Anti
|
5~300Hz/random operating
|
|
Power supply
|
ATX
|
|
Installation
|
1U rack
|
|
Material
|
Surface sandblasting oxidation process (silver)
|
|
 |
