HTPC32 WeChat Printer (1037U/J1900) |
|
|
| Product name : HTPC32 WeChat Printer (1037U/J1900) |
| Item : HTPC32 |
| Details : |
Oder Information
|
No.
|
Model NO.
|
Processor
|
Mainboard
|
Memory
|
Storage
|
LAN
|
USB
|
Front Audio
|
WIFI
|
Adapter
|
OS
|
|
1
|
HTPC32
|
1037U/1.80GHz
|
M19-N2
|
No
|
No
|
1*RTL8111E
|
6
|
With
|
N/A
|
12V/5A
|
XP
|
|
2
|
H32100C
|
1037U/1.80GHz
|
M19-N2
|
2G
|
32G
|
1*RTL8111E
|
6
|
With
|
N/A
|
12V/5A
|
XP
|
|
3
|
H32320C
|
3217U/1.80GHz
|
M100_I3
|
2G
|
32G
|
1*RTL8111E
|
6
|
With
|
N/A
|
12V/5A
|
XP
|
|
4
|
H32180C
|
J1800/2.41GHz
|
M50_N18
|
2G
|
32G
|
1*RTL8111F
|
6
|
With
|
N/A
|
12V/3A
|
WIN7
|
|
5
|
H32190C
|
J1900/2.00GHz
|
M50-NC
|
2G
|
32G
|
1*RTL8111F
|
6
|
With
|
N/A
|
12V/3A
|
WIN7
|
HTPC32 WeChat Printer (1037U/J1900)
HTPC32
♦ Light silver black
♦ 197mm*197mm*32mm (L*W*H)
♦ Fan cooling structure
♦ Celeron1037U/1.80GHz dual core CPU
♦ Intel®HD Graphics
♦ 1*DDR3/1.5V/2GB memory
|
Chassis
|
Color
|
Light silver black
|
|
Size
|
197mm*197mm*32mm (L*W*H)
|
|
Structure
|
Fan cooling structure
|
|
Material
|
galvanized steel sheet
|
|
Motherboard
|
Model No.
|
ITX-M19_N2
|
|
Processor
|
Celeron1037U/1.80GHz dual core CPU
|
|
Graphics
|
Intel®HD Graphics
|
|
Memory
|
1*DDR3/1.5V/2GB memory
|
|
Storage
|
2.5’HDD
|
N/A
|
|
CF
|
N/A
|
|
SSD
|
32G
|
|
System Feature
|
Ethernet
|
1* LAN (RTL 8111E)
|
|
USB
|
6* USB2.0
|
|
Serial Port
|
1* COM
|
|
Display
|
1* VGA
|
|
Audio
|
1* MIC,1*Line-out
|
|
Expansion Interface
|
2* MINIPCIE (one is MSATA,the other one is WIFI interface)
|
|
Indicator
|
N/A
|
|
System Control
|
Power switch
|
|
Wireless
|
2* WIFI/3G SMA antenna (optional)
|
|
Power
|
Power
|
12V/5A adapter
|
|
Reliability
|
Installation
|
Desktop or wall-mounted
|
|
Operating T
|
-10°C~60°C
|
|
Storage T
|
-20°C~70°C
|
|
Relative humidity
|
5%-95%, no condensing
|
|
Vibration
|
0.5g rms/5-500HZ/random/operating
|
|
 |
