Name:
|
Embedded motherboard(ITX-A945GM) |
|
Spec:
|
ITX-A945GM |
|
Memo:
|
|
|
Class:
|
Mini-ITX Motherboards |
|
CPU
|
Intel Core 2 ( FSB ) 800MHz/533/400, 1M/2M/4M/
|
|
Chipset
|
Intel 945GM +ICH7 chipsets
|
|
Main Memory
|
Support DDR2 2GB 800/667/533
|
|
VGA
|
INTEL® GMA950 Graphics Core
|
|
Ethernet
|
Onboard two RTL8111C 2*1000/Base-T Ethernet controllers
|
|
IDE&CF & SATA
|
TWO SATA devices
Support ATA-100, data transfer rate up to 100MB/sec
One CF Care
One enhanced PCI IDE channels which support up to 2 IDE devices
|
|
PCI AUDIO & COM
|
Support one PCI devices
Support HDAudio
Support Five COM
|
|
System BIOS
|
Award BIOS with 8MB Firmware Hub
ACPI/PnP supported
Software WatchDog supported
|
|
I/O Output
|
One DB-15 VGA port
Double Deck downstream USB 2.0 ports
Two RJ-45 LAN ports
PS/2 mouse and keyboard connectors
AV/S
|
|
Expansion Slots
|
One PCI slot
|
|
Form Factor
|
Flex-ATX @ 170mm (L) ×170 mm (W),
|
Online Shop: http://www.aliexpress.com/store/312429Payment Terms: T/T,Western Union,PAYPAL,ESCROW
