Order Information
|
No.
|
Model NO.
|
Processor
|
Motherboard
|
Memory
|
Storage
|
LAN
|
COM
|
USB
|
WIFI
|
Adapter
|
OS
|
|
1
|
IPC-NF263C
|
N2600/1.66GHz
|
N26
|
2G
|
32G
|
2*RTL8111E
|
6
|
6
|
N/A
|
12V/5A
|
XP
|
|
2
|
IPC-NF263D
|
N2600/1.66GHz
|
N26
|
2G
|
64G
|
2*RTL8111E
|
6
|
6
|
N/A
|
12V/5A
|
XP
|
|
3
|
IPC-NF283C
|
N2800/1.86GHz
|
N28
|
2G
|
32G
|
2*RTL8111E
|
6
|
6
|
N/A
|
12V/5A
|
XP
|
|
3
|
IPC-NF283D
|
N2800/1.86GHz
|
N28
|
2G
|
64G
|
2*RTL8111E
|
6
|
6
|
N/A
|
12V/5A
|
XP
|
♦ Fanless heatsink structure
♦ Al alloy chassics, compact features,flexbile installation
♦ Support WIFI/3G moudle,provide a board SIM expansion slot
♦ 1*VGA/1*HDMI
♦ 2*RTL 8111E Gigabit ethernet port, support wake on LAN
♦ I/O Interfaces:6xCOM,1xVGA,2xLan, 1xAduio, 6xUSB,1xHMDI
|
Chassis
|
Color
|
Black
|
|
Size
|
182mm*108mm*63.5mm (L*W*H)
|
|
Structure
|
AI alloy Fanless design
|
|
Material
|
AI alloy
|
|
Motherboard
|
Model No.
|
EPIC-N26 VER1.2
|
|
Processor
|
Intel@Atom N2600/1.66G dual core CPU
|
|
Graphics
|
Intel®3600 Graphics
|
|
Memory
|
1*DDR3/1.5V/2GB memory
|
|
Storage
|
2.5’ HDD
|
N/A
|
|
CF
|
N/A
|
|
SSD
|
64G/128G optional
|
|
System Feature
|
Ethernet
|
2* LAN (RTL 8111E)
|
|
USB
|
6* USB2.0
|
|
Serial Port
|
6* COM,COM2 supportsRS485
|
|
Display
|
1* VGA/1*HDMI
|
|
Audio
|
1*Line-out
|
|
Expansion Interface
|
2* Mini PCIE (one is MSATA,the other one is WIFI interface)
|
|
Indicator
|
1 for power state, 1 for HDD
|
|
System Control
|
Power switch
|
|
Wireless
|
2* WIFI/3G SMA antenna (optional)
|
|
Power
|
Power
|
12V/5A adapter
|
|
Reliability
|
Installation
|
Desktop or wall-mounted
|
|
Operating T
|
-10°C~60°C
|
|
Storage T
|
-20°C~70°C
|
|
Relative humidity
|
5%-95%, no condensing
|
|
Vibration
|
0.5g rms/5~500Hz/random operating
|
